3 tonna lyftara með hliðarbúnaði til sölu

Vörulýsing

---

3 Ton forklift attachment Side Shifter (SSS30)

Structure and characteristic

Good field of vision for operator: Combining hydraulic cylinder with attachment part to make space smaller and widen field of vision for operator.

Fast and easy installation: No any extra operation for welding and drilling is required, just quick hook shifter onto fork lift directly.

Uniform side shifting speed: Connecting pole of hydraulic cylinder could be amounted on both sides so makes the attachment move on left and right smoothly and uniformly.

Hydraulic cylinder with high pressure: Cylinder could be worked on 250bar from system. No additional pressure reducer id required.

Long working life of upper sliding supporting: Using brazed material for upper sliding supporting, under normal maintenance the supporting is more wear-resisting, more instensity and toughness, has longer working life.

Myndbönd

---

Fyrirmynd	Stærð / Hleðslumiðstöð	Opnun Svið D	Árangursrík Þykkt C	Lárétt Miðja af þyngdaraflinu CGH	Þyngd	Lóðrétt Miðja af þyngdaraflinu CGV	Armur Lengd L	Armur Hæð A	Rammi Breidd B	Uppsetning Bekk
	(kg / mm)	(mm)	(mm)	(mm)	(kg)	(mm)	(mm)	(mm)	(mm)
G09B12-200A26	1200/500	550-2000	184	420	660	300	1000	1200	1140	2
G09B11-200A46	1100/600			425	675		1200
G09B10-200A66	1000/700			430	605		1400
G09B16-200A46	1600/600	550-2000	187	430	725	300	1200	1200	1140	2
G09B15-200A66	1500/700			460	790		1400
G09B14-200A86	1400/800			475	815		1600
G09B15-200A49	1500/600			430	810	305	1200	1500

Grunnupplýsingar

---

Model NO.: SSS30
Notkun: Þungur þvinga
Standard: Standard
Brand: Cascard
Forklift Attachment: Side Shifter
Opnun: 550-2000
Horizontal: 420
Flutningspakki: Seaworthy Packing
Origin: Xiamen, China

Efni: Metal
Uppbygging: G þvinga
Skilyrði: Nýtt
Name: 3 Ton Forklift Attachment Side Shifter (SSS30)
Capacity/: 1200/500
Effective: 184
Vörumerki: SHYTGER
Tæknilýsing: CE, SGS, ISO
HS kóða: 84312090

---



Side Shifter í 4. flokki
